Creasing Matrix

Tooling Component

Mechanical strips fixed to a cutting plate define the precise location and width of a fold in paperboard during the die cutting process. A creasing matrix provides the female channel that works in tandem with the male creasing rule to deform the fibers into a controlled hinge. This alignment ensures the board folds without cracking or wandering from the intended line.

It is required for high speed automated filling where carton dimensions must be exact.

Installation Procedure

Technicians apply the matrix by sticking the self adhesive strips onto the platen or the cutting plate. The locator strip ensures the channel is perfectly centered over the steel rule before the operator removes the carrier. Choosing the correct width depends on the thickness and the moisture content of the board being processed.

If the channel is too narrow, the board will split along the outer surface. A channel that is too wide results in a loose fold that lacks the tension required for square carton formation. This process must be repeated for every new layout on the press.

Production Durability

Wear on the matrix surface eventually leads to a loss of crease definition. High volume runs require matrix materials made from presspahn or composite plastics to maintain accuracy over thousands of impressions. Replacing a worn matrix is a standard maintenance task during long production shifts.
